Objectives: To assess the effectiveness of rapid diagnostic tests (RDTs) for bacterial identification and antibiotic susceptibility testing in clinical and antibiotic stewardship outcomes compared with standard practice in hospitals, and to apply a Sankey diagram to present the findings and illustrate study heterogeneity. Study design: Systematic review and meta-analysis of experimental and observational studies which included at least one prescribing or clinical outcome of RDTs in hospital in-patients. Sub-group analysis was used to assess heterogeneity in summary effect estimates. A Sankey diagram was then used to show the pattern and quality of evidenceon RDT outcomes. Results: 58 studies from 14 countries were included. The introduction of RDTs did not significantly reduce in-hospital mortality (RR 0.83, 95% CI 0.60 - 1.15) or length of stay (weighted mean difference = -0.36, 95% CI -1.67 to 0.96). There was high heterogeneity in outcomes. Conclusion: There is no clear evidence that the routine use of RDTs for bacterial identification and antibiotic susceptibility testing improves clinical outcomes in hospital inpatients. Sankey diagrams may be a useful further way succinctly to present the pattern and quality of evidence in systematic reviews, especially when it is heterogeneous and not easily amenable to meta-analysis.
